OSPF Reference Bandwidth: Definition and Configuration

OSPF cost could be set explicitly or calculated automatically using the link’s bandwidth and OSPF reference bandwidth. In this tutorial, I explain the definition of OSPF reference bandwidth, how to adjust it, and more.

Upon the completion of this lesson, you will be able to answer the following questions:

  • What is reference bandwidth in OSPF?
  • What is the function of the auto-cost reference-bandwidth command?
  • Why would you want to change the OSPF default reference bandwidth?
  • How do I change the reference bandwidth in OSPF?
  • How does OSPF calculate its metric or cost?
  • How does OSPF check reference bandwidth?
  • How does OSPF determine the cost of an interface?
  • How does OSPF reference bandwidth get used?
  • How to use the auto-cost reference-bandwidth command?

ospf-reference-bandwidthospf-reference-bandwidth

In the rest of this tutorial, we use the following network topology consisting of 4 routers. All interfaces belong to area 0, and the bandwidths of some interfaces have been changed to demonstrate facts related to OSPF reference bandwidth.

Router Interface Bandwidth
R3 FastEthernet 0/1 2.5Gbps
R4 GigabitEthernet 0/0 10Gbps
R4 Serial 1/0 56kbps

Here are the links to download the configurations applied to the routers.

Router R1 Router R2 Router R3 Router R4

What is OSPF Reference Bandwidth?

OSPF reference bandwidth is a value OSPF uses along with bandwidth to calculate the link’s cost if the cost was not set manually. By default, OSPF divides the reference bandwidth by the bandwidth and assigns the resulting value to the link’s cost.

OSPF Cost = (OSPF Reference Bandwidth) / (Link Bandwidth)

100 Mbps is the default value for OSPF reference bandwidth on Cisco IOS, IOS-XE, and IOS-XR.

Link Bandwidth depends on the interface type (Loopback, T1, Ethernet, Fast Ethernet, Gigabit Ethernet, 10-Gigabit Ethernet, Serial, OC48, etc) by default. The table below shows the default bandwidth for several interface types and the corresponding cost based on different OSPF reference bandwidth values.

Interface Type Default Bandwidth OSPF Cost
Reference bandwidth of 100Mbps Reference bandwidth of 1Gbps Reference bandwidth of 10Gbps
Loopback 8000000 1 1 1
Serial 56 1785 17857 178571
T1 1544 64 647 6476
Ethernet 10000 10 100 1000
Fast Ethernet 100000 1 10 100
Gigabit Ethernet 1000000 1 1 10
OC48 2500000 1 1 4
10-Gigabit Ethernet 10000000 1 1 1

When the value of OSPF Reference Bandwidth is lower than the link’s bandwidth, OSPF sets the cost to 1. For example, with OSPF reference bandwidth equal to 100 Mbps, loopback, Gigabit Ethernet, OC48, and 10-Gigabit Ethernet interfaces get an OSPF of 1 (Examples 1, 2, 3, and 4 )

R1# show interfaces loopback 0
Loopback0 is up, line protocol is up
  Hardware is Loopback
  Internet address is 10.0.1.1/24
  MTU 1514 bytes, BW 8000000 Kbit/sec, DLY 5000 usec,

omitted output



R1# show ip ospf interface loopback 0
Loopback0 is up, line protocol is up
  Internet Address 10.0.1.1/24, Area 0
  Process ID 1, Router ID 10.0.1.1, Network Type LOOPBACK, Cost: 1
  Loopback interface is treated as a stub Host

Example 1 – Displaying the bandwidth and OSPF cost of R1’s loopback 0 interface

R2# show interfaces gigabitEthernet 0/0
GigabitEthernet0/0 is up, line protocol is up
  Hardware is i82543 (Livengood), address is ca02.0888.0008 (bia ca02.0888.0008)
  Internet address is 10.0.12.2/24
  MTU 1500 bytes, BW 1000000 Kbit/sec, DLY 10 usec,
     reliability 255/255, txload 1/255, rxload 1/255


omitted output


R2# show ip ospf interface gigabitEthernet 0/0
GigabitEthernet0/0 is up, line protocol is up
  Internet Address 10.0.12.2/24, Area 0
  Process ID 1, Router ID 10.0.24.2, Network Type BROADCAST, Cost: 1
  Topology-MTID    Cost    Disabled    Shutdown      Topology Name
        0           1         no          no            Base


omitted output

Example 2 – Displaying the bandwidth and OSPF cost of R2’s GigabitEthernet 0/0 interface

R3# show interfaces fastethernet 0/1
FastEthernet0/1 is up, line protocol is up
  Hardware is AmdFE, address is cc03.089c.0001 (bia cc03.089c.0001)
  Internet address is 10.0.34.3/24
  MTU 1500 bytes, BW 2500000 Kbit/sec, DLY 100 usec,
     reliability 255/255, txload 1/255, rxload 1/255


omitted output


R3# show ip ospf interface fastethernet 0/1
FastEthernet0/1 is up, line protocol is up
  Internet Address 10.0.34.3/24, Area 0
  Process ID 1, Router ID 10.0.34.3, Network Type BROADCAST, Cost: 1
  Transmit Delay is 1 sec, State BDR, Priority 1


omitted output

Example 3 – Displaying the bandwidth and OSPF cost of R3’s FastEthernet 0/1 interface

R4# show interfaces gigabitEthernet 0/0
GigabitEthernet0/0 is up, line protocol is up
  Hardware is i82543 (Livengood), address is ca04.063f.0008 (bia ca04.063f.0008)
  Internet address is 10.0.34.4/24
  MTU 1500 bytes, BW 10000000 Kbit/sec, DLY 10 usec,

omitted output


R4# show ip ospf interface gigabitEthernet 0/0
GigabitEthernet0/0 is up, line protocol is up
  Internet Address 10.0.34.4/24, Area 0
  Process ID 1, Router ID 10.0.34.4, Network Type BROADCAST, Cost: 1

omitted output

Example 4 – Displaying the bandwidth and OSPF cost of R4’s GigabitEthernet 0/0 interface

Default OSPF Reference Bandwidth

The default OSPF reference bandwidth on Cisco IOS is 100Mbps. The table below provides the default OSPF reference bandwidth on different router operating systems.

Router OS Default OSPF Reference Bandwidth
Cisco IOS 100Mbps
Cisco IOS XE 100Mbps
Cisco IOS XR 100Mbps
Cisco NX-OS 40Gbps
Juniper JunOS 100Mbps

Adjusting OSPF Reference Bandwidth on Cisco IOS

The goal of adjusting OSPF reference bandwidth is to best calculate the OSPF cost according to the interface’s bandwidth. On Cisco IOS, OSPF reference bandwidth can range from 1 to 4294967 Mbps. Using a small value will make all interfaces equal to OSPF while using a too-high value leads to very high OSPF costs that may exceed the maximum cost of 65535 that can be assigned to an interface. However, setting the OSPF reference bandwidth to the speed of the fastest router interface in the current OSPF domain would be enough.

The auto-cost reference-bandwidth bw allows changing the default value of OSPF reference bandwidth, where bw is a number between 1 and 4294967 in Mbps.

R2(config-router)# auto-cost reference-bandwidth 10000

To display the current OSPF reference bandwidth on a particular router, use the show ip ospf command (Example 6).

Finally, make sure that OSPF reference bandwidth is the same on all routers in the current OSPF autonomous system.

R2# show ip ospf
 Routing Process "ospf 1" with ID 10.0.24.2
 Start time: 00:03:49.320, Time elapsed: 00:41:10.548
 Supports only single TOS(TOS0) routes
 Supports opaque LSA
 Supports Link-local Signaling (LLS)
 Supports area transit capability
 Event-log enabled, Maximum number of events: 1000, Mode: cyclic
 Router is not originating router-LSAs with maximum metric
 Initial SPF schedule delay 5000 msecs
 Minimum hold time between two consecutive SPFs 10000 msecs
 Maximum wait time between two consecutive SPFs 10000 msecs
 Incremental-SPF disabled
 Minimum LSA interval 5 secs
 Minimum LSA arrival 1000 msecs
 LSA group pacing timer 240 secs
 Interface flood pacing timer 33 msecs
 Retransmission pacing timer 66 msecs
 Number of external LSA 0. Checksum Sum 0x000000
 Number of opaque AS LSA 0. Checksum Sum 0x000000
 Number of DCbitless external and opaque AS LSA 0
 Number of DoNotAge external and opaque AS LSA 0
 Number of areas in this router is 1. 1 normal 0 stub 0 nssa
 Number of areas transit capable is 0
 External flood list length 0
 IETF NSF helper support enabled
 Cisco NSF helper support enabled
 Reference bandwidth unit is 10000 mbps
    Area BACKBONE(0)
        Number of interfaces in this area is 2
        Area has no authentication
        SPF algorithm last executed 00:01:59.948 ago
        SPF algorithm executed 7 times
        Area ranges are
        Number of LSA 7. Checksum Sum 0x02FB20
        Number of opaque link LSA 0. Checksum Sum 0x000000
        Number of DCbitless LSA 0
        Number of indication LSA 0
        Number of DoNotAge LSA 0
        Flood list length 0

Example 5 – Displaying general information about OSPF

OSPF Issue Caused by OSPF Reference Bandwidth

When you adjust OSPF reference bandwidth manually, Cisco IOS displays the following message.

% OSPF: Reference bandwidth is changed.
Please ensure reference bandwidth is consistent across all routers.

Basically, configuring different OSPF reference bandwidth values on routers in the same OSPF routing domain would not cause routing loops. A routing loop occurs when router A forwards a packet, destined for a particular network, to a next-hop router B, which sends the packet back to A.

However, suboptimal routing may occur because links with lower bandwidth gets lower OSPF cost.
